Supports Intel® Smart Response Technology, Intel® Rapid Start Technology, Intel® Smart Connect Technology

LAN

Realtek® 8111G, 1 x Gigabit LAN Controller(s)

Audio

Realtek® ALC887 8-Channel High Definition Audio CODEC *2

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

Puertos USB

Intel® H87 chipset :

6 x USB 3.0/2.0 port(s) (4 at back panel, blue, 2 at mid-board)

Intel® H87 chipset :

8 x USB 2.0/1.1 port(s) (2 at back panel, black, 6 at mid-board)

Caracteristicas Especiales

ASUS 5X PROTECTION :

- ASUS DIGI+ VRM - Phase digital power design

- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention

- ASUS ESD Guards - Enhanced ESD protection

- ASUS All 5K-Hour Solid Capacitors - 2.5x long lifespan with excellent durability

- ASUS Stainless Steel Back I/O - 3x more durable corrosion-resistant coating

ASUS EPU :

- EPU

ASUS Exclusive Features :

- GPU Boost

- AI Suite 3

- Ai Charger

- Anti-Surge

- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface

- Network iControl

- USB 3.0 Boost

- Disk Unlocker

ASUS Quiet Thermal Solution :

- Stylish Fanless Design Heat-sink solution

- ASUS Fan Xpert 2

ASUS EZ DIY :

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 2

ASUS Q-Design :

- ASUS Q-Slot

- ASUS Q-DIMM

Puertos I/O Traseros

1 x PS/2 keyboard (purple)

1 x PS/2 mouse (green)

1 x DVI-D

1 x D-Sub

1 x HDMI

1 x LAN (RJ45) port(s)

4 x USB 3.0

2 x USB 2.0

3 x Audio jack(s)

Internal I/O

1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)

3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)

1 x COM port(s) connector(s)

6 x SATA 6Gb/s connector(s)

1 x CPU Fan connector(s) (1 x 4 -pin)

2 x Chassis Fan connector(s) (2 x 4 -pin)

1 x S/PDIF out header(s)

1 x 24-pin EATX Power connector(s)

1 x 8-pin ATX 12V Power connector(s)

1 x Front panel connector(s)

1 x Internal speaker connector(s)

1 x System panel(s)

1 x Clear CMOS jumper(s)
