CPU

AMD AM3+ FX™/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors

Supports AM3+ 32 nm CPU

Supports CPU up to 8 cores

Supports CPU up to 140 W

AMD Cool 'n' Quiet™ Technology

Chipset

AMD 970/SB950

Memoria

4 x DIMM, Max. 32GB, DDR3 2133(O.C.)/1866/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory

Dual Channel Memory Architecture

System Bus

Up to 4.8 GT/s HyperTransport™ 3.0

Soporte Multi GPU

Supports AMD Quad-GPU CrossFireX™ Technology

Slots de Expansión

1 x PCIe 2.0 x16 (blue)

1 x PCIe 2.0 x16 (x4 mode, black)

2 x PCIe 2.0 x1

2 x PCI

LAN

Realtek® 8111F, 1 x Gigabit LAN Controller(s)

Audio

Realtek® ALC887 8-Channel High Definition Audio CODEC *1

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

Audio Feature :

- ASUS Noise Filter

- Optical S/PDIF out header(s) at mid-board

Puertos USB

ASMedia® USB 3.0 controller :

2 x USB 3.0/2.0 port(s) (2 at back panel, blue)

AMD SB950 controller :

12 x USB 2.0/1.1 port(s) (6 at back panel, black, 6 at mid-board)
